If you are going to use SIEMENS convert from S5 to S7 tool, there is no problem with wringing messages but you must have no errors in conversion to be completed.

You should revise the resolution all of analog inputs / outputs in S5 and study the processes behavior after using analog inputs / outputs cards from S7 because there are different in resolution between S5 and S7 card

Many Step 5 functions have been replaced in Step 7 by integrated functions that you do not need to convert, so you should be aware about all of S5 functions/instructions were used in your S5 project.

For example:

SD is an ON-delay timer, in Step 7 you have replace them with TON functions from IEC instructions library, or the older ST-timer SODT.

MUL 16 and DIV 16 can be replaced by MUL_I and DIV_I in Step 7.

So remove these lines of code when you convert the s5 program, insert the correct functions in Step 7 to replace them.

Replace the FB 242 call in the S5 program by a *I (or MUL_I in LAD) or *D (or MUL_DI in LAD) instruction in the S7 program.

Most industrial automation systems is built with integration in mind, which is why it is such a popular and successful tool for modernizing your plant and increasing your ROI at the same time. WIACS will work with you to migrate – create a custom system that will focus on maintaining the integrity of your current plant functions and integrate seamlessly into your existing systems.

You can open the manual of any CPU to get information about the SF and BF.

If SF is red, system fault occurs. There is any error in the system or RIO. Like Hardware or Software fault.

Industrial Communication Protocols types:

MPI (Multi-Point Interface)

Siemens (MPI) is a proprietary interface of the programmable logic controller SIMATIC S7 of the company Siemens, It is used for connecting the stations programming (PC or personal computer), operator consoles, and other devices in the SIMATIC family. This technology has inspired the development of protocol Profibus.

Profibus (usually styled as PROFIBUS, as a portmanteau for Process Field Bus) is a standard for fieldbus communication in automation technology and was first promoted in 1989 by BMBF (German department of education and research) and then used by Siemens. … PROFIBUS is a standardized, open, digital communications system for all areas of application in manufacturing and process automation

EtherNet/IP is an industrial network protocol that adapts the Common Industrial Protocol to standard Ethernet. EtherNet/IP is one of the leading industrial protocols in the United States and is widely used in a range of industries including factory, hybrid and process.

For more information, check this video:

https://youtu.be/Rc_hCBAuHpk

Each SIMATIC S7-300 possesses an integrated interface. There are many possible ways to attach a PC or laptop to an MPI: – Integrated ISA- Communication processors for the PG – ISA- Communication processors for the PC (e.g. MPI-ISA- Card) – PCI- Communication processors for the PC (e.g. CP5611) – PCMCIA- Communication processors for the laptop (e.g. CP5511) – Adapter for the communication over the serial interface of a PC or laptop (e.g. PC-Adapter).

The following steps below describe the calibration and parameters of a PC-Adapter for a PC.

1. Call Set PG-PC-Interface. (Start SIMATIC STEP 7 Set PG-PC-Interface)
2. The module Select is available as the MPI-interface (Select).
3. Select the desired module e.g. choose PC-Adapter and Install (PC-Adapter Install). 4. Make sure the desired module is present (PC Adapter Close).
4. Choose Properties of PC-Adapter (MPI) (PC Adapter (MPI) Properties).
5. Select COM-Port and the Transmission Rate of the serial interface.
6. Set the MPI-Address, Timeout, Transmission Rate and Highest Node Address.
7. Accept the configuration (OK).

For more information, check these videos:

https://youtu.be/H1vR0YEDJSo

https://youtu.be/FkXf6yE-baM
